Home - Products -HDMI Splitter

M-SP49

LINK-MI LM-SP49 HD Splitter with Scaler

Introduction:
1. Built in Scaler inside;
2. With USB interface, most of the 1080P and below video can be
decoded and the video can be played automatically and circularly.
3, support 180 degree flip;
4. Modular design. The output can be customized according to the
actual situation of customers. The single machine supports 4-20
channels of customized output.
5, output resolution supports 1080P@60/720P@60/1024*768@60 optional.
6, the maximum output distance can reach more than 20 meters.
7, the standard 19 inch 1U chassis, 100-240V AC input.

Description
